With reference to marine elevators, the applicable rules and regulations are the following:
KINGLIFT Marine Elevator is fully compliant with all the rules and regulations set forth by the competent authorities regarding marine elevators. Book your next service with us to benefit from qualified and certified assistance.
KINGLIFT Marine is a global maritime service company. Our multi-brand expert team is committed to keeping vessels safe and compliant, anywhere in the world. With technical know-how, 24/7 responsiveness, and unparalleled spare part sourcing we are your global beacon.
With KINGLIFT Marine, you can be 100% sure your elevator is SAFE.
KINGLIFT Marine, a distinguished name in the marine elevator services industry, stands as a beacon of reliability when it comes to the maintenance, repair, and troubleshooting of marine escalators. Our firm dedication to excellence has solidified our position as your trusted partner in ensuring the smooth operation of these vital systems. With a team of experienced technicians and a robust technical department at our disposal, we offer a comprehensive range of services aimed at keeping your marine elevators in top-notch condition.
One of our core offerings is standard maintenance, a proactive approach to elevator care that is essential in preventing unexpected breakdowns and ensuring maximum uptime. Our highly skilled technicians conduct periodical adjustments and calibrations of the equipment, leaving no room for performance faults. They also oversee the replacement of critical components such as main wire ropes, governor ropes, guide shoe linings and more. These routine interventions not only extend the lifespan of your marine elevator but also enhance its overall efficiency and safety.
In the unfortunate event of a breakdown, you can count on KINGLIFT Marine to swiftly come to your aid. Our repair service team is well-prepared, armed with a pre-attendance checklist that allows them to execute a meticulously planned course of action. Our suite of comprehensive solutions includes both mechanical and electrical repairs, regardless of whether your marine elevator is a modern model or a seasoned workhorse. We recognize that downtime can be costly and disruptive, which is why our dedicated team works tirelessly to minimize it.
Identifying the root cause of malfunctions in marine elevators is a challenge that we readily embrace. Our troubleshooting service is designed to pinpoint the exact issue and provide you with the most efficient and effective repair strategy. This critical step is essential in not only resolving the immediate problem but also preventing potential future complications. Our service engineers and product specialists collaborate closely to ensure that your marine elevator is restored to optimal working condition.
At KINGLIFT Marine Elevator, we understand that each vessel and marine elevator is unique, with its own set of requirements and challenges. That’s why our approach is highly customized. We take into account the specific needs of your elevator system and tailor our services accordingly. Whether it’s a routine check-up, a complex repair, or an intricate troubleshooting process, our team is well-equipped to handle it all.
Staying at the center stage of elevator technology is a pillar of our service. We invest in continuous training and education for our technicians, ensuring they are well experienced in the latest advancements in marine elevator systems. Additionally, we deploy the latest diagnostic tools and equipment to streamline our processes and enhance the precision of our services. This fusion of expertise and technology allows us to provide unparalleled support to our clients.
KINGLIFT Marine also offers a diverse range of spare parts for various elevator components, ensuring that your marine elevator is equipped with the latest and most reliable components. Our modernization services are tailored to meet the evolving requirements of your elevator systems, keeping them up-to-date with the latest safety and efficiency standards.
We prioritize safety through rigorous inspections and installations. Our safety inspection services cover every aspect of your marine elevator, ensuring compliance with the highest safety standards. Whether it’s a new installation or an upgrade, our skilled technicians ensure that your elevator operates safely and efficiently.
Operating in Major ports and serving diverse ships, KINGLIFT Marine is your global partner in elevator solutions. Our services extend beyond routine maintenance, repairs, and troubleshooting. We offer installations in various ports, addressing the elevator requirements of a wide range of ships, including those equipped with Hyundai marine elevators.
Our devotion to qualitative work is strong. From the selection of components to the execution of services, we adhere to the highest standards. KINGLIFT Marine is not just a service provider; we are your reliable partner, ensuring that your marine elevators meet and exceed quality requirements.
Partner with us for all your marine elevator needs and experience the peace of mind that comes with having the best in the business by your side. Today to explore our tailored solutions, cutting-edge technology, and skilled professionals dedicated to elevating your marine elevator experience. Trust KINGLIFT Marine for excellence, safety, and efficiency in every vertical movement.
Our team is at your disposal 24/7, 365 days a year.
Services Contracts
Do you want to save on your costs for service on your fleet’s elevators? With our maintenance programs we guarantee proper periodical adjustments and calibration of the equipment. The program will help prevent breakdowns and guarantee high uptime of your marine elevators.
For fleet owners who want absolute peace of mind about the functioning of their marine elevators, KINGLIFT Marine Elevator offers the ideal solution: service contracts. Regular, scheduled servicing can substantially reduce the operational cost of your elevators, increase the uptime, improve the safety level and save you a lot of headaches.
|
Certification |
Service |
Parts |
Travel |
|
|---|---|---|---|---|
|
Full Service |
✓ |
✓ |
✓ |
✓ |
|
Semi Full |
✓ |
✓ |
||
|
Monitoring |
✓ |
One certification every 12 months, including a load test every fifth year
Regular check-up, perform adjustments like landing height, closing of doors, etc.
All main wear and tear replacement parts (cables, motor, gearbox, etc.)
Travel time to your vessel, incl. overnight accommodation and meals on board (if needed).
To assure you of the safety and efficiency of your marine elevators, our qualified technicians will perform a thorough survey at the beginning of the service contract:
We will track service intervals, parts replacement and certifications needed. Wherever you are in the world, you can consult with our technicians about any of your elevators.
5.8.1 Electric Marine Elevators
Electric marine elevators shall conform to Part 2, except as modified by Section 5.8.
5.8.1.1 Hoistway Enclosures
The hoistway shall be entirely enclosed over all of its height by means of a continuous solid steel fire-resistive enclosure with an equivalent fire-resistance rating of 1 h as defined in the 1974 Amendment of SOLAS Regulation 3. Elevators with total travel within one compartment of the vessel shall be permitted to be enclosed with expanded metal having openings a maximum of 25 mm (1 in.). The hoistway enclosure shall be of sufficient strength to prevent contact between the enclosure and the car or counterweight when the enclosure is subjected to a force of 1112 N (250 lbf) applied at right angles at any point over an area of 100 mm x 100 mm (4 in. x 4 in.).
5.8.1.2 Separate Counterweight Hoistways
The hoistway shall be entirely enclosed over all of its height by means of a continuous solid steel fire-resistive enclosure with an equivalent fire-resistance rating of 1 h as defined in the 1974 Amendment of SOLAS Regulation 3. Where a separate counterweight hoistway is provided on an elevator that has total travel within a single compartment of the vessel, it shall be permitted to be enclosed with expanded metal having openings a maximum of 25 mm (1 in.). The hoistway enclosure shall be of sufficient strength to prevent contact of the car or counterweight and its enclosure when the enclosure is subjected to a force of 1112 N (250 lbf) applied at right angles at any point over an area of 100 mm x 100 mm (4 in. x 4 in.).
5.8.1.3 Protection of Space Below the Hoistway
All elevators shall be provided with elevator counterweight safeties conforming to 2.17.4.
5.8.1.4 Hoistway Entrances
Except when opening and closing in response to control signals, each hoistway door shall have means to prevent door movement and slamming when the vessel is subjected to conditions up to and including a 30-deg roll and a 10-deg pitch simultaneously.
5.8.1.5 Top Emergency Exits
It shall be permissible to open the top emergency exit cover from the top of the car or from within the car. This exit cover shall be provided with an electric contact conforming to 2.14.5.7. The breaking of this contact shall cause the power to be removed from the elevator driving motor and brake and the power shall be restored only by a manually operated reset switch located inside the elevator enclosure. Means shall be provided within the elevator car to gain access to the top emergency exit. A fixed vertical ladder of noncombustible material shall be provided on the inside of the hoistway to permit access from the top of the car to the hoistway entrance above. Means shall be provided to snap latch the cover closed or fully open.
5.8.1.6 Illumination of Cars
Elevators used primarily for the movement of personnel shall have the electrical power meet the requirements of IEEE 45, with car enclosure lighting to be supplied from the vessel's final emergency power source. In addition, a standby (emergency) lighting power source shall be furnished conforming to 2.14.7.1.3.
5.8.1.7 Traction Driving Machines
5.8.1.7.1
Traction driving machines shall be provided with a device to cause the elevator to stop and remain stopped if
(a) when a start is initiated, the driving machine does not rotate
(b) the car or counterweight is stopped in a downward motion by an obstruction that causes the suspension ropes to slip on the driving sheave
5.8.1.7.2
This device shall function in a time that does not exceed the smaller of the following values:
(a) 45 s
(b) the time for the car to travel the full travel, plus 10 s, with a minimum of 20 s if the full travel time is less than 10 s
5.8.1.7.3
This device shall not affect operation from the top-of-car inspection station.
5.8.1.7.4
Driving machines shall be provided with a manual means of operation, allowing the car to be moved to the nearest landing in the event of a power failure. This shall be done by having the end of the drive motor shaft arranged to receive a crank. The manual effort required to move the car in the upward direction with rated load shall not exceed 400 N (90 lbf). One crank or tool shall be furnished for this purpose.
5.8.1.8 Emergency Operation and Signal Devices
(a) Shipboard elevators shall be required to conform to 2.27.1.1.
(b) In ships or offshore drilling rigs in which a watchman is not continuously available to take action when the required emergency signal is operated, the elevator shall be provided with one of the following additional emergency signaling devices:
(1) a telephone connected to a central telephone exchange system
(2) means within the car for communicating with or signaling to an emergency service that operates 24 h each day
5.8.1.9 Special Conditions
Elevators shall be designed and installed to function in accordance with Sections 2.14 through 2.28 when operating under the following conditions inherent to the installation location:
(a) continuous vibration: 2 mm (0.08 in.) peak to peak of frequency 0 Hz to 25 Hz
(b) rolling: ± 10 deg, period 10 s
(c) pitching: ± 5 deg, period 7 s
(d) heaving amplitude: A 3.8, period 10 s, calculated by the formula4 = 3.8 - 0.01 (L - 250), where L is the length of the ship, in meters, measured between the perpendicular taken at extremities of the deepest subdivision loadline
5.8.1.10 Handrails
Cars shall be fitted with at least one handrail.
5.8.1.11 Flooring
Cars shall be fitted with slip-resistant flooring.
5.8.2 Hydraulic Shipboard Elevators
Hydraulic shipboard elevators shall conform to Part 3, except as modified by 5.8.1 and 5.8.2.
5.8.2.1 Storage Tanks
Power unit oil storage tanks shall be constructed in such a manner to prevent spillage of hydraulic fluid under the following conditions inherent to the installation location:
(a) rolling: ± 45 deg
(b) pitching: ± 5 deg
5.8.2.2 Special Conditions
Elevators shall be designed and installed to function in accordance with Part 3 when operating under the following conditions inherent to the installation location:
(a) continuous vibration: 2 mm peak to peak of frequency 0 Hz to 25 Hz
(b) rolling: ± 10 deg, period 10 s
(c) pitching: ± 5 deg, period 7 s
(d) heaving amplitude: A 3.8, period 10 s, calculated by the formula4 = 3.8 - 0.01 (L - 250), where L is the length of the ship, in meters, measured between the perpendicular taken at extremities of the deepest subdivision loadline
5.8.2.3 Handrails
Cars shall be fitted with at least one handrail.
5.8.2.4 Flooring
Cars shall be fitted with slip-resistant flooring.
5.8.3 Rack-and-Pinion Shipboard Elevators
Rack-and-pinion shipboard elevators shall conform to Section 4.1, except as modified by 5.8.1 and 5.8.3.
5.8.3.1 Special Conditions
Elevators shall be designed and installed to function in accordance with Section 4.1 when operating under the following conditions inherent to the installation location:
(a) continuous vibration: 2 mm peak to peak of frequency 0 Hz to 25 Hz
(b) rolling: ± 10 deg, period 10 s
(c) pitching: ± 5 deg, period 7 s
(d) heaving amplitude: A 3.8, period 10 s, calculated by the formula A = 3.8 - 0.01 (L - 250), where L is the length of the ship, in meters, measured between the perpendicular taken at extremities of the deepest subdivision loadline
5.8.3.2 Handrails
Cars shall be fitted with at least one handrail.
5.8.3.3 Flooring
Cars shall be fitted with slip-resistant flooring.
